C.15.4

SSH Console Interface

These instructions cover the setup and maintenance of the 1093A/B/C using the Secure Shell (SSH)
Console Interface. Secure Shell is an alternative to using the Telnet protocol, and used for securely
gaining access to a remote system like the Model 1093A/B/C. Configure all 1093A/B/C settings
through one of the Ethernet ports. Instructions on using the Web Interface for the same purpose
are found in section C.15.3.
Any Secure Shell (SSH) client, like OpenSSH or PuTTY
SSH and type in the device's IP address and connect. For Mac users, Terminal works fine. At the
command prompt (
Press ENTER after typing the IP address. Shortly, you should be prompted for the password.
Type in the password and press ENTER. The console interface should open and appear similar to
Figure C.31.
Startup Page – System Status
When logging in to the Option 34 using SSH console the opening screen should be the System
Status information page. This provides an overview of the operation of the Option 34, NTP/PTP
servers. Figure C.31 illustrates the opening page.
If you do not know the IP address of the port you are connected to, press the STATUS key
on the front panel. Messages should appear separately for NET1 (port 1) and for NET2 (port 2).
If the IP addresses do not appear, then check to make sure a network cable is connected between
the chosen port and an active network. If there is no DHCP server on the network, a port set
for DHCP will not display. Factory default settings include one port set with a static IP address.
Make sure that the Link LED is lit.
IP addresses for all Ethernet ports of the installed Option 34 are either set automatically by the
Dynamic Host Configuration Protocol (DHCP) server on your network, or set to a static address.
The front panel will indicate the IP address of each port.
is the command prompt) type:
Figure C.31: SSH Console Interface – Startup Screen
TM
, is suggested. Make sure to select
ssh clockoption@ip address
