C.15 Option 34: NTP/PTP Server
NTP Terms
NTP – reveals that it is either running or stopped.
Root Dispersion – (or dispersion) represents the maximum error of the local clock relative
to the reference clock.
Offset – (or clock offset) represents the amount to adjust the local clock to bring it into
correspondence with the reference clock.
Frequency – frequency offset (PPM) relative to hardware clock.
System Jitter – is defined as the root-mean-square (RMS) average of the most recent offset
differences, and it represents the nominal error in estimating the offset (of the system).
Clock Jitter – is defined as the root-mean-square (RMS) average of the most recent offset
differences, and it represents the nominal error in estimating the offset (of the clock).
Clock wander – is the RMS of exponentially weighted frequency differences. This is not
used directly, but can, along with the jitter, be a highly useful monitoring and debugging
tool.
Stratum – the level of each server in the hierarchy is defined by a stratum number. Primary
servers are assigned stratum one.
NTP Configure
To configure NTP follow these instructions. Use the cursor keys to select NTP, then Configure and
press ENTER. Figure C.40 illustrates the NTP configuration page. Choices for the NTP Version
include Versions 1, 2, 3 and 4. Multicast and Broadcast addresses may be typed in the assigned
boxes.
Figure C.40: NTP Configure Page Using SSH
163
