32
7.2

Setup Menus

No. Setup Menus
1 Set Main RS-232?
2 Set Local Hour?
3 Set Out-Of-Lock?
4 Set Back Light?
5 Set System Delays?
6 Set Prog. Pulse?
7 Set IRIG Time Data?
8 Set Event/Deviation?
9 Set Auto Survey?
10 Set Position Hold?
11 Set Option Control?
7.2.1

Default Firmware Settings

When shipped from the factory, and unless specified otherwise, all models will be configured with
default settings. Most users elect to modify the clock settings to fit their locale and desired opera-
tion. Default settings are listed in Table 7.2.
Menu Item
Main RS-232
Out-of-Lock
System Delays
IRIG-B Time Data
Auto Survey
Option Control
7.2.2

Numeric Data Entry Mode

Numeric data entry mode is activated anytime you enter a menu that requires a change in numerical
value and press either the UP or DOWN key to change the digit value. When in this mode, the
function of the SETUP and ENTER keys change to give left and right cursor control.
Setup Items
Main RS-232 Port Parameters and Broadcast
Set Local Offset, Daylight Saving mode
Set Time Interval Before Alarm
Set to ON, OFF or AUTO
Set Antenna Cable Delay in Nanoseconds
Set Mode, Pulse Width and Time Zone
Set IRIG-B Time Zone and IEEE-1344
Set for Event, or 1–PPS Deviation
Set Survey mode
Set ON or OFF
Set Main board and Aux. board options
Table 7.1: Front-Panel Setup Menus
Default Menu Item
9600, 8, N, 1 Local Offset & DST
01 minute Backlight
60 ns Prog Pulse
UTC, 1344 OFF Event/Deviation
Power On Survey Position Hold
None –
Table 7.2: Default Firmware Settings
The Setup Menus
Default
none, OFF
Auto
Sec. per Pulse
1 PPS Deviation
ON
–
