168
12. PTP Application Stops – notifies when PTP service stops.
13. SNMP Application Start – notifies when SNMP service starts.
14. SNMP Application Stop – notifies when SNMP service stops.
Trap Receivers – Select this item to enable SNMP to send messages to snmp receivers.
1. IP Address 1 – Type in the IP address of snmp receiver number 1.
2. IP Address 2 – Type in the IP address of snmp receiver number 2.
3. IP Address 3 – Type in the IP address of snmp receiver number 3.
MIB Table
The text of the MIB table, listed below, is current as of the publication date of this manual, and
is produced by Arbiter's technical team. Updates are available by download from the Arbiter web
site. Also, the SNMP agent that runs on Option 34 is also available for download and use in the
Model 1093A/B/C. The MIB table is normally loaded in a MIB browser and the agent is normally
uploaded into the Option 34.
–
– ARBITER ALL MIB, Revision 0.0003, 3 DEC 2012
–
ARBITER-ALL-MIB DEFINITIONS ::= BEGIN
IMPORTS
MODULE-IDENTITY, OBJECT-TYPE, enterprises, Integer32, Unsigned32 FROM SNMPv2-SMI
TEXTUAL-CONVENTION, TruthValue FROM SNMPv2-TC
;
–
– The position within the OID hierarchy of this MIB:
–
arbiter OBJECT IDENTIFIER ::=
sys MODULE-IDENTITY
LAST-UPDATED "201205250000Z"
ORGANIZATION "Arbiter Systems"
CONTACT-INFO
"
Arbiter Systems, Inc.
Paso Robles, CA
Tel: +1 805 237 3831"
DESCRIPTION
"This MIB module defines a MIB which provides general information
about an Arbiter Systems' product."
::= arbiter 1
device OBJECT IDENTIFIER ::=
diag OBJECT IDENTIFIER ::=
config OBJECT IDENTIFIER ::=
gnss OBJECT IDENTIFIER ::=
enterprises 39849
sys 1
sys 2
sys 3
sys 4
Options List
