Option 03 Signal Definitions - Arbiter Systems 1092A Operation Manual

102
Signal
IRIG-E:
IRIG-H:
10 MPPS:
5 MPPS:
1 MPPS:
100 kPPS:
10 kPPS:
1 kPPS:
100 PPS:
60 PPS:
50 PPS:
10 PPS:
IRIG-D/1 PPM:
1 PPH:
1 PPS:
Programmable:
Out-of-Lock:
IRIG-B (Modified
Manchester):
Description
IRIG format E time code.
IRIG format H time code.
10,000,000 pulse-per-second (PPS) square wave, synchronous to the
1-PPS output.
5,000,000-PPS square wave, synchronous to the 1-PPS output.
1,000,000-PPS square wave, synchronous to the 1-PPS output.
100,000-PPS square wave, synchronous to the 1-PPS output.
10,000-PPS square wave, synchronous to the 1-PPS output.
1,000-PPS square wave, synchronous to the 1-PPS output.
100-PPS square wave, synchronous to the 1-PPS output.
60-PPS square wave, synchronous to the 1-PPS output.
50-PPS square wave, synchronous to the 1-PPS output.
10-PPS square wave, synchronous to the 1-PPS output.
IRIG format D time code (1 pulse per minute), rising edge on time.
1 pulse per hour, rising edge on time.
(10 ms HI), synchronous to 1 PPS/GPS. Also available on clock Mod-
els 1084A/B/C and 1088B.
Outputs a single pulse at a preprogrammed time, or a continuous
pulse train having a period of one day or less. Pulse width is ad-
justable from 0.01 to 600 seconds. Also available on clock Model
1093A/B/C.
Normally HI after acquisition of satellite signals. Toggles LO nn
minutes after loss of satellite signal lock. Range for nn is 00 to
99 minutes, and is set using the SETUP menu or RS-232C (refer to
clock Operation Manual). Setting of 00 disables this function (output
remains HI). This output follows the standard Out-of-Lock function
on the clock.
IRIG format B time code, Manchester encoded with 1-kPPS carrier,
and data transitions on time mark. Also available on clock Models
1088B and 1084A/B/C.
Table C.1: Option 03 Signal Definitions
Options List
