Arbiter Systems 1092A Operation Manual page 212

194
open drain, see 200-Volt FET
Option
08, terminals with SWC, 8
10, terminals with SWC, 8
Options
07, IEC-320 connector, 8
Option 03, 103
power, 07, 11
power, 08, 12
power, 10, 12
Options List
Option 01, Backlighted LCD, 100
Option 02, Battery Backup, 101
Option 03, Four Additional Outputs, 102
Option 04, ON/OFF Switch, 106
Option 07, IEC-320 power supply, 107
Option 08, 10 – 60 Vdc power supply, 108
Option 10, 110 – 350 Vdc power supply, 109
Option 19, Second RS-232C, 110
Option 20A, Four Fiber Optic Outputs, 111
Option 27, 8–Channel High Drive, 114
Option 28, Power System Monitor, 119
Option 29, 4 outputs, dry contacts, 128
Option 32/33, NTP Server, 133
Option 34, NTP/PTP Server, 140
Option 91, 1–microsecond accuracy, 152
Option 92, IRIG-B Modulated Output, 152
Option 93, Out-of-Lock Relay, 152
Option 94, RS-422/485 Driver, 152
Option 95, Four BNC Connectors, 153
Option 96, Prog Pulse Output, 153
Option 97, IRIG-B reconfig to Prog Pulse,
154
Option 98, Event Input, 154
options list, 99
output signal
description, 52
panels
drawing
front, 6
rear, 8, 51
front, 5
rear, 5
position display modes, 32
datum, 32
Position Hold commands, 84
power supply
voltage, 18
programmable pulse
description, 55
pulse width, 55
with 200-Volt FET, 55
rack mount ears
mounting instructions, 2
rear panel, see panels, drawing, rear
Relay
available, 10
configuring, 39
operation, 61
Option 93, 152
Out-of-Lock
extend startup, 39
solid state, 128
RG-11
cable, 20
crimp tool, 20
ROM date, ii
RS-232C
command set, 65
setup, 36
serial command
antenna delay
set, 87
arm event trigger, 77
backlight auto, 82
backlight off, 82
backlight on, 82
broadcast ABB, 74
broadcast ASCII + Quality, 72
broadcast ASCII Std, 71
broadcast custom, 66
broadcast Event Data, 71
broadcast Extended ASCII, 72
broadcast Kissimmee, 75
broadcast NMEA183 GLL, 73
broadcast NMEA183 ZDA, 74
broadcast Philippe, 75
broadcast Status, 72
broadcast strings, 71
broadcast Vorne Std, 71
INDEX
