Chapter 3: System Setup
If you are installing the 802.11b/g/n INTEL: 2200BNHMW mini card module
2. Tighten screws onto the mounting holes to secure the bracket.
(half size), before processing with the installation, please assemble the Wi-Fi
module bracket first to full size module by following the instructions below:
1. Align the mounting holes on the Wi-Fi mini card module to the mounting
holes on the Wi-Fi module bracket.
Mounting holes
Wi-Fi module bracket
75
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
IPPC 1560T/1960T/2160P Series and APPC 1560T User Manual
