Chapter 3: System Setup
3. Insert the module into the socket at an approximately 30 degree angle.
Apply firm even pressure to each end of the module until it slips into the
socket. The gold-plated connector on the edge of the module will almost
completely disappear inside the socket.
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
4. Insert the CPU into the FCPGA988 socket.
95
IPPC 1560T/1960T/2160P Series and APPC 1560T User Manual
