8. LIST OF ERROR CODES
Feed mechanism-related errors
Code
X-feed motor home position cannot be detected. Problem with X-feed motor or poor X home position sensor
connection.
E200
Turn off the power, and then check that connectors P17, P21 and P8 on the main P.C. board are properly
connected.
X-feed motor stopped due to a problem.
E201
Turn off the power, and then check if there are any problems in the X-feed direction.
Turn off the power, and then check that connectors P17 and P21 on the main P.C. board are properly connected.
X-feed motor stopped due to a problem during sewing.
E204
Turn off the power, and then check if there are any problems in the X-feed direction.
Turn off the power, and then check that connectors P17 and P21 on the main P.C. board are properly connected.
X-feed motor stopped due to a problem while moving to the sewing start position.
E205
Turn off the power, and then check if there are any problems in the X-feed direction.
Turn off the power, and then check that connectors P17 and P21 on the main P.C. board are properly connected.
X-feed motor stopped due to a problem during test feeding.
E206
Turn off the power, and then check if there are any problems in the X-feed direction.
Turn off the power, and then check that connectors P17 and P21 on the main P.C. board are properly connected.
Y-feed motor home position cannot be detected. Problem with Y-feed motor or poor Y home position sensor
connection.
E210
Turn off the power, and then check that connectors P18, P22 and P8 on the main P.C. board are properly
connected.
Y-feed motor stopped due to a problem.
E211
Turn off the power, and then check if there are any problems in the Y-feed direction.
Turn off the power, and then check that connectors P18 and P22 on the main P.C. board are properly connected.
Y-feed motor stopped due to a problem during sewing.
E214
Turn off the power, and then check if there are any problems in the Y-feed direction.
Turn off the power, and then check that connectors P18 and P22 on the main P.C. board are properly connected.
Y-feed motor stopped due to a problem while moving to the sewing start position.
E215
Turn off the power, and then check if there are any problems in the Y-feed direction.
Turn off the power, and then check that connectors P18 and P22 on the main P.C. board are properly connected.
Y-feed motor stopped due to a problem during test feeding.
E216
Turn off the power, and then check if there are any problems in the Y-feed direction.
Turn off the power, and then check that connectors P18 and P22 on the main P.C. board are properly connected.
Feed motor stopped due to a problem.
E230
Reduce the sewing speed or change the operation settings to the settings for heavy-weight materials.
Ask the place of purchase for details on the setting method.
Work clamp-related errors
Code
Work clamp home position cannot be detected. Problem with work clamp motor or poor work clamp home
position sensor connection.
E300
Turn off the power, and then check that connectors P19, P23 and P8 on the main P.C. board are properly
connected.
Work clamp raised or lowered position cannot be detected.
E301
Turn off the power, and then check if there are any problems in the work clamp vertical direction. Turn off the
power, and then check that connectors P19 and P23 on the main P.C. board are properly connected.
53
Cause of error and remedy
Cause of error and remedy
BAS-341H, BAS-342H
