5.1.17 16-** Data Readouts

Parameter
Number
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-05 Main Actual Value [%]
16-09 Custom Readout
16-10 Power [kW]
5 5
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor Current
16-15 Frequency [%]
16-18 Motor Thermal
16-30 DC Link Voltage
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-60 Digital input 18,19,27,33
16-61 Digital input 29
16-62 Analog Input 53 (V)
16-63 Analog Input 53 (mA)
16-64 Analog Input 60
16-65 Analog Output 42 [mA]
16-68 Pulse input 33
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-86 FC Port REF 1
16-90 Alarm Word
16-92 Warning Word
16-94 Ext. Status Word
Table 5.20
62
VLT
Parameter Description
MG02C602 - VLT
®
Micro Drive FC 51 Programming Guide
Default Value 2 Setup
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
20 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
0 1 set-up
®
is a registered Danfoss trademark
Change During Conversi
Operation on Index
TRUE 0
TRUE -3
TRUE -1
TRUE 0
TRUE -2
TRUE -2
TRUE -3
TRUE -3
TRUE 0
TRUE -1
TRUE -2
TRUE -1
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE -2
TRUE -2
TRUE 0
TRUE -1
TRUE -1
TRUE -3
TRUE 0
TRUE 0
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
Type
Uint16
Int32
Int16
Uint16
Int16
Int32
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint8
Uint16
Uint8
Uint8
Uint16
Uint16
Uint8
Int16
Int16
Int32
Uint16
Uint8
Uint16
Uint16
Uint16
Uint16
Uint16
Uint8
Int16
Int16
Int16
Uint32
Uint32
Uint32
