Parameter Descriptions
[22] Ready, No
Thermal Warning
[23] Remote Ready, No
Thermal Warning
[24] Ready, Voltage OK Frequency converter is ready for
4 4
[25] Reverse
[26] Bus OK
[28] Brake, No Warn
[29] Brake Ready/No
Fault
[30] Brake Fault (IGBT)
[32] Mech. Brake
Control
[36] Control Word Bit
11
[41] Below Reference,
low
[42] Above Reference,
high
[51] Local Reference
Active
[52] Remote Reference
Active
[53] No Alarm
[54] Start Cmd Active
[55] Running Reverse
[56] Drive in Hand
Mode
[57] Drive in Auto
Mode
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
30
®
VLT Micro Drive FC 51 Programming Guide
Frequency converter is ready for
operation and no over-temperature
warning is present.
Frequency converter is ready for
operation in Auto mode, and no over-
temperature warning is present.
operation and mains voltage is within
specified voltage range.
Motor runs/is ready to run clockwise
when logic = 0 and counter clockwise
when logic = 1. Output changes as
soon as reversing signal is applied.
Active communication (no time-out) via
serial communication port.
Brake is active, and no warnings are
present.
Brake is ready for operation, and no
faults are present.
Protects frequency converter if fault on
brake modules is present. Use relay to
cut out main voltage from frequency
converter.
Enables control of external mechanical
brake, see parameter group 2-2*
Mechanical Brake.
Bit 11 in control word controls relay.
Reference is lower than set in 4-54
Warning Reference Low.
Reference is higher than set in 4-55
Warning Reference High.
See parameter group 13-1*
Comparators. If comparator 0 is
evaluated as TRUE, output goes high.
Otherwise, it is low.
See parameter group 13-1*
Comparators. If comparator 1 is
evaluated as TRUE, output goes high.
Otherwise, it is low.
See parameter group 13-1*
Comparators. If comparator 2 is
evaluated as TRUE, output goes high.
Otherwise, it is low.
MG02C602 - VLT
[63] Comparator 3
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[81] SL Digital Output
B
5-40 Function Relay
Option:
[0] No Operation Select function from available relay output
*
5-41 On delay, Relay
Option:
[0.01 s] [0.00-600.00 s] Enter the delay of the relay cut-in time.
*
5-42 Off delay, Relay
Option:
[0.01 s] [0.00-600.00 s] Enter the delay of the relay cut-off
*
4.6.5 5-5* Pulse Input
Set 5-15 Terminal 33 Digital Input to choice [32] pulse input.
Now terminal 33 handles a pulse input in the range from
Low frequency, 5-55 Terminal 33 Low Frequency, to 5-56
Terminal 33 High Frequency. Scale frequency input via 5-57
Terminal 33 Low Ref./Feedb. Value and 5-58 Terminal 33 High
Ref./Feedb. Value.
®
is a registered Danfoss trademark
See parameter group 13-1*
Comparators. If comparator 3 is
evaluated as TRUE, output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules.
If Logic Rule 1 is evaluated as TRUE,
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules.
If Logic Rule 2 is evaluated as TRUE,
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules.
If Logic Rule 3 is evaluated as TRUE,
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules.
If Logic Rule 3 is evaluated as TRUE,
output goes high. Otherwise, it is low.
See 13-52 SL Control Action. When Smart
Logic Action [39] Set dig. out. A high is
executed, input goes high. When Smart
Logic Action [33] Set dig. out. A low is
executed, input goes low.
Function:
range.
Function:
If the Selected Event condition changes
before the On delay timer expires, the
relay output is unaffected. The function
to control the relay see 5-40 Function
Relay.
Function:
time. If the Selected Event condition
changes before the off delay timer
expires, the relay output is unaffected.
The function to control the relay see
5-40 Function Relay.
