Parameter Descriptions
4.10.6 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
Select boolean input to define Smart Controller Event.
See 13-40 Logic Rule Boolean 1 for choices and
descriptions.
4 4
13-52 SL Controller Action
Array [20]
Option:
[0] Disabled
*
[1] No Action
[2] Select Set-up1
[3] Select Set-up2
[10] SelectPresetRef0 Selects preset reference 0
[11] SelectPresetRef1 Selects preset reference 1
[12] SelectPresetRef2 Selects preset reference 2
[13] SelectPresetRef3 Selects preset reference 3
[14] SelectPresetRef4 Selects preset reference 4
[15] SelectPresetRef5 Selects preset reference 5
[16] SelectPresetRef6 Selects preset reference 6
[17] SelectPresetRef7 Selects preset reference 7
[18] SelectRamp1
[19] SelectRamp2
[22] Run
[23] RunReverse
[24] Stop
[25] Qstop
[26] DCstop
[27] Coast
[28] Freeze Output
[29] StartTimer0
[30] StartTimer1
[31] StartTimer2
[32] SetDO42Low
[33] SetRelayLow
[38] SetDO42High
[39] SetRelayHigh
[60] ResetCounterA
[61] ResetCounterB
44
®
VLT Micro Drive FC 51 Programming Guide
Function:
Select action corresponding to SLC event.
Actions are executed when corresponding
event (13-51 SL Controller Event) is
evaluated as True.
Function is disabled.
No action is taken.
Changes active set-up to Set-up 1.
Changes active set-up to Set-up 2.
Selects ramp 1
Selects ramp 2
Issues start command to frequency
converter.
Issues start reverse command to
frequency converter.
Issues stop command to frequency
converter.
Issues quick stop command to frequency
converter.
Issues DC stop command to frequency
converter.
frequency converter coasts immediately.
All stop commands including coast
command stop the SLC.
Freezes output frequency.
Starts timer 0.
Starts timer 1
Starts timer 2
Set Digital output 42 low.
Set Relay low.
Set Digital output 42 high.
Set Relay high.
Resets counter A to 0.
Resets counter B to 0.
