Service and Replacement
Parts Manual
MANUAL MC-T50E-02
Model Numbers:
C0-T50-80
T h e B e s t W a y
T o G o
A b o u t Y o u r
B u s i n e s s
Powered by AC Motor
Control System
WARNING
READ THE OPERATOR'S MANUAL BEFORE OPERATING
THIS VEHICLE.
The operator's manual contains important information
regarding the safe operation of this vehicle.
Starting Serial Number: 198576
G
Ending Serial Number: 210539
