Optional equipment
12.4.

External Wi-Fi antenna, remote (optional)

Fig. 12.4: Remote Wi-Fi antenna (optional)

Technical data
Application
Mounting location
Number of antennas
Type
Frequency range
Antenna gain
Impedance
Polarization
Dimensions
Weight
Connector labeling
Scope of delivery
Maximum transmitting
power
Advantech-DLoG
Wi-Fi IEEE 802.11 a/b/g/n dual-band
For detached (remote) installation, e.g. on the roof of the forklift
1
Omnidirectional antenna
Band 1: 2400 to 4900 MHz
Band 2: 4900 to 6000 MHz
Band 1: Max. 4 dBi (without loss through the cable)
Band 2: Max. 6.5 dBi (without loss through the cable)
50 Ω
Vertical/Horizontal
Ø 86 x 43 mm (Ø 3.39" x 1.69")
0.3 kg (0.66 lbs)
N type or TNC N, jack, female, bottom
RSMA plug for RSMA socket on the terminal
3 m antenna cable
100 mW / 20 dBm
