Mechanical installation

Recommend sequence for the mechanical installation
Requirement: The vehicle/installation location must be prepared (e.g. connection to the ignition, correct
voltage, etc.)
−
Determine a suitable mounting position for the DLT-V72.
−
Secure device mounting at the vehicle (RAM Mount etc.).
−
Connect external accessories to the DLT-V72.
−
Install an easily accessible disconnecting device, such as a switch close to the device.
−
Connect all cables.
−
Close the DLT-V72 with cable cover.
−
Mount the DLT-V72 on the device mounting bracket.
7.1. Safety notice – observe before installing
Risk of injury and damage due to improper mechanical installation.
These mounting instruction are directed to skilled personnel. Only qualified skilled personnel
may perform the mechanical installation work on the DLT-V72.
If the DLT-V72 is incorrectly mounted, any DLoG GmbH warranty for this device will be void.
The mounting of the DLT-V72 must not endanger the safety of the operating personnel.
Example: When mounting to forklifts, the driver's field of view must remain free.
Hazardous voltage, electric shock from contact with live parts.

Do not put the DLT-V72 into operation if it is visibly damaged.

Do not open or modify the DLT-V72.
Risk of injury due to weight and sharp-edged parts.
The DLT-V72 can fall down and cause injuries due to its weight.
The strain relief rail can have sharp edges and cause cutting injuries.

Always hold the DLT-V72 by the housing with both hands.

Never use the antenna cap as a handle. It can break due to the weight involved.

Do not hold the DLT-V72 by the strain relief rail.
Use the assistance of a second person for installation work.
