Chore-Time Hyflo Instruction Manual page 22

Part Numbers (for Fans Manufactured September 2004 to July 2007)48" and 52" Hyflo® Fans Installation and Operators Instruction
Part Numbers (for Fans Manufactured September 2004 to July 2007)
Fans that were Manufactured from September 2004 to July of 2007 used four different Cone Panels, Housing Panels,
and a Door stop Wire and Spring. The Part Numbers below are for Fans that were manufactured during that time.
1
3 2
Item Part Description
1 5" Hyflo Top Panel
®
9" Hyflo Top Panel
®
2 5" Hyflo Bottom Panel
®
9" Hyflo Bottom Panel
®
Cone Panel, RH Hyflo
3
4
Cone Panel, Bottom Hyflo
Cone Panel, Top Hyflo
5
Cone Panel, LH Hyflo
6
Wire
7
Spring
8
22
5 3
3 3
3 4
48" Fan Part Numbers
5" Deep Housing 49451-XX
9" Deep Housing 49515-XX
Part No.
48671
49207
49473
49513
49444
®
49442
®
49441
®
49443
®
49597
49596
3 6
3 7
3 8
52" Fan Part Numbers
5" Deep Housing 49511-XX
9" Deep Housing 49519-XX
Models-XX Part No.
All 48685
All 49459
All 49509
All 49517
All 49508
All 49506
All 49505
All 49507
All 49597
All 49596
5
6
3
4
Models-XX
All
All
All
All
All
All
All
All
All
All
MV1832P
