48" and 52" Hyflo® Fans Installation and Operators Instruction Manual
Item Part Description
1 Motor, 1ph, 1.5hp, 1725 rpm
Motor, 1ph, 1hp, 1725 rpm
Motor, 3ph, 1.5hp, 1725 rpm
Motor, 3ph, 1hp, 1725 rpm
Motor, 1ph, 1.5hp
Motor, 3ph, 1.5hp
2 Shroud, Fan
3 Post, Fan
4 Motor Support, Idler Drive
5 Bearing Support, Idler Drive
6 Tensioner Support
7 Tensioner Assy with Idler
8 Bearing, 1" Pillow Block
9 Fan Shaft
Fan Blade, High Efficiency
10
Fan Blade, Standard
Fan Blade, High Capacity
11 Sheave, Driven Composite AFD84100
Sheave, Driven Composite AFD94100
12 5" Hyflo Top Panel
®
9" Hyflo Top Panel
®
13 5" Hyflo R.H. Side Panel
®
9" Hyflo R.H. Side Panel
®
14 5" Hyflo L.H. Side Panel
®
9" Hyflo L.H. Side Panel
®
15 5" Hyflo Bottom Panel
®
9" Hyflo Bottom Panel
®
Sheave, Driver AK27
16
Sheave, Driver AK30
Sheave, Driver AK32
18 Screen, 56 x 56 x 12
19 Clip, V Galv. Hyflo Screen
20 Cone Panel
21 Nylon Washer
22 Shutter Clip
23
5/16-24 x 1" HXHD Bolt
5/16-24 x 1" SQHD Bolt
24 Grill, Galv. Cone
25 Frame, Hyflo
®
26 Plate, SS Fan Door Pivot
27 Spring, Door Closing
28 Magnet, .125 Thk. x .50 Dia.
29 Bracket, Cone Support
30 Nylon Coated Door Stop Cable
31 V-Belt A59
V-Belt A60
V-Belt AX59
V-Belt AX60
32 Hyflo Door
®
33 Pop Rivet, SS 1/8 x .40
34 Support, Hyflo
35 Cone Clip (Optional)
36 Idler with Bushings (For Repair)
37 Screen Spring (Package of 4)
MV1832P
Part No.
Door
Door Spring
®
Hyflo® Fan Parts (Manufactured after July 2007)
48" Fan Part Numbers
5" Deep Housing 49451-XX
9" Deep Housing 49515-XX
Models-XX
49903 -21
37729 -22, -23
47693 -52
40157 -42
-- --
48608 -41,-51
48362 All
48393 All
48396 All
48395 All
48394 All
48429 All
50553 All
48397 All
45932 -23
28140 -22, -42, -52
46748 -21, -41, -51
54898 -51, -52, -23
54897 -21, -22, -41, -42
51045 All
51047 All
49474-2 All
49514-2 All
49474-1 All
49514-1 All
51044 All
51046 All
1381 -23
8773 -21, -22, -41, 42
48504 -51, -52
48794 All
50409 All
51040 All
4856 All
36729 All
-- All
49447 All
49439 All
49598 All
49629 All
48427 All
49445 All
50618-2 All
48505 -23,-51,-52
48430 -21,-22,-41,-42
-- --
-- --
49446 All
48936 All
49450 All
-- --
50879 All
54480-4 All
52" Fan Part Numbers
5" Deep Housing 49511-XX
9" Deep Housing 49519-XX
Part No. Models-XX
49903 -22
-- --
-- --
-- --
48580 -21
48608 -41,-51,-42,-52
47710 All
48072 All
48396 All
48395 All
48394 All
48429 All
50553 All
48397 All
-- --
48507 -22, -42, -52
48125 -21, -41, -51
54898 -51, -52
54897 -21, -22, -41, -42,
51049 All
51051 All
49510-2 All
49518-2 All
49510-1 All
49518-1 All
51048 All
51050 All
-- --
8773 -21, -22, -41, -42
48504 -51, -52
48794 All
50409 All
51041 All
4856 All
36729 All
-- All
49501 All
49499 All
49598 All
49629 All
48427 All
49445 All
50618-1 All
48505 -23,-52
48430 -22, 42
48615 -51
48541 -21,-41
49500 All
48936 All
49450 All
49504 All
50879 All
54480-4 All
