Comtech EF Data CSAT-5060 Installation And Operation Manual page 92

5 to 25 Watt C-Band Transceiver
Remote Control
Arguments
for
Command
Command
or
(Instruction
Parameter
Response
Code and
Type
to Query
qualifier)
Mute Mode MUT= 1 byte,
value of 0,1
TX Mute UMU= 1 byte,
value of 0,1
RX Mute DMU= 1 byte,
value of 0,1
TX Slope USM= 1 byte,
Mode value of 0,1
TX Slope USA= 3 bytes
Adjust
RX Slope DSM= 1 byte,
Mode value of 0,1
Description of arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Command or Query.
Mute Mode, where:
0 = Unmuted after Frequency change,
1 = Muted after Frequency change.
Example: MUT=1
Command or Query.
TX Mute, where:
0 = Transmitter Unmuted,
1 = Transmitter Muted
Example: UMU=1
Command or Query.
RX Mute, where:
0 = Receiver Unmuted,
1 = Receiver Muted
Example: DMU=1
Command or Query.
TX Slope Mode, where:
0 =Manual Mode,
1 = Calibrated Mode.
Example: USM=1
Command or Query.
TX Slope Adjust, between 0.0 and 1.0.
Resolution = 0.1.
Example: USA=0.3
Command or Query.
RX Slope Mode, where:
0 =Manual Mode,
1 = Calibrated Mode.
Example: DSM=1
Response to
Command
(Slave to Master)
MUT=(message ok)
MUT?(received ok,
but invalid argument
found)
UMU=(message ok)
UMU?(received ok,
but invalid argument
found)
DMU=(message ok)
DMU?(received ok,
but invalid argument
found)
USM=(message ok)
USM?(received ok,
But invalid argument
found)
USA= (message ok)
USA? (received ok,
but invalid arg.
found)
DSM=(message ok)
DSM?(received ok,
But invalid argument
found)
A-8
MN/CSAT506025.IOM
Query
(Instruction Response to query
code and
(Slave to Master)
qualifier)
MUT? MUT=x
(same format as command
argument)
UMU? UMU=x
(same format as command
argument)
DMU? DMU=x
(same format as command
argument)
USM? USM=x
(same format as command
argument)
USA? USA=x.x
(same format as command
argument)
DSM? DSM=x
(same format as command
argument)
Revision 1
