Chapter 7. Maintenance And Troubleshooting; Figure 7-1 Converter Signal And Interconnecting Cable Diagram - Comtech EF Data CSAT-5060 Installation And Operation Manual

Chapter 7. MAINTENANCE AND
This appendix is intended to provide procedures to assist operator and maintenance personnel in
the checkout, maintenance and troubleshooting of the transceiver. Comtech EF Data
recommends that spare replacement transceivers be used to replace transceivers removed from the
system for maintenance. The input and output signals, the interconnecting cables and the location
of the modules are as shown in Figure 7-1.
J3
AC Power
J4
Ext Ref In, 5/10 MHz
J5
COMM, Remote Control
J1
IF IN, Tx
J6
IF Out, Rx
TROUBLESHOOTING
Power Supply
Maintenance &
Control
UPCONVERTER SSPA
J7
DOWNCONVERTER
CSAT-5060/050
7-1
Figure 7-1. Converter Signal
and Interconnecting Cable
Diagram
RF In
