Chapter 5. LOW NOISE AMPLIFIER
5.1 LNA I
NSTALLATION
The AS/0438, Mounting LNA Switch Kit, is the kit for the Redundant System. It can be mounted
using one of the following kits:
•
SPAR Mount, 1 X 2 Antenna, Mounting Kit P/N, AS/0422
•
SPAR Mount, 1.75 X 4 Antenna, Mounting Kit, P/N AS/0501
•
Feed Horn Mounting Kit, P/N AS/0502
Note: Single-thread installation is covered in Section 5.4.
5.2 T R
OOLS EQUIRED
The following tools are recommended for unit installation.
QTY
1
5.3 LNA M
OUNTING
Part No.
AS/0438
AS/0461
AS/0502
Description
Adjustable wrench
Alternate: Set of various box wrenches
K
ITS
Nomenclature
Kit, LNA Switch Mounting
Kit, Waveguide CPR229
Bracket, TX/RX Filter Support
INSTALLATION
5-1
QTY
1
1
1
