GE PACSystems RX7i Reference Manual page 303

Appendix A. Performance Data
Production Period
SN [Consumption Timeout*]
(ms)
A 500
B 500
C 500
D 300
E 300
F 300
G 200
H 200
I 200
J 100
K 100
L 100
M 50
N 50
O 50
P 30
Q 30
R 30
S 20
T 20
U 20
The following table shows the chart for setting up EGD exchanges on Embedded Ethernet for RSTi-EP
CPE100/CPE115 with a no sweep load and no network traffic. The table is a compilation of results based
on testing with two RSTi-EP CPE100/CPE115 Systems in which one is acting as the EGD Producer and
the other is acting as the EGD Consumer.
SN Production Period
[= 50% Consumption Timeout]
(ms)
A 500
B 300
C 200
D 100
E 50
F 30
G 20
292
Data size per Exchange
(Bytes)
1400
200
10
1400
200
10
1400
200
10
1400
200
10
1400
200
10
1400
200
10
1400
200
10
Data size per Exchange
(Bytes)
1400
1400
1400
1400
1400
1400
1400
PACSystems* RX7i, RX3i and RSTi-EP CPU Reference Manual
Maximum Number of EGD
Exchanges ( Recommended)
254
255
255
166
255
255
109
255
255
54
255
255
27
127
230
16
75
136
11
50
91
Maximum Number of EGD Exchanges
(Recommended)
8
8
8
8
8
8
8
GFK-2222AD
