Sutter Instrument LB10-3 Operation Manual page 57

Command Command Command Command
Status Status
Status Status
All Motors Power All Motors Power
All Motors Power All Motors Power
On On On On
All Motors Power All Motors Power All Motors Power All Motors Power
Off Off
Off Off
Fast- - - - mode Shutter Fast Fast Fast mode Shutter mode Shutter mode Shutter
Soft Soft Soft- - - - mode Shutter Soft mode Shutter mode Shutter mode Shutter
Neutral Density Neutral Density Neutral Density- - - - Neutral Density
mode Shutter mode Shutter mode Shutter mode Shutter
Batch Transfer Batch Transfer Batch Transfer Batch Transfer
Value Value Value Value
(Decimal, (Decimal, (Decimal, (Decimal,
hexadecimal, & hexadecimal, & hexadecimal, & hexadecimal, &
binary) binary)
binary) binary)
executed in quick succession.
Returns status of unit in two bytes
204
CC
11001100
Instruct the controller to power on all motors.
206
CE
11001110
207 Instruct the controller to power off all motors.
CF
11001111
Sets the shutter to fast mode (SmartShutter only).
220 + 1 or 2
Second byte indicates Shutter A (1) or B (2).
DC + 01 or 02
11011100 +
00000001 or
00000010
221 + 1 or 2 Sets the shutter to soft mode (SmartShutter only).
Second byte indicates Shutter A (1) or B (2).
DD + 01 or 02
10111011 +
00000001 or
00000010
Sets the shutter to neutral-density mode
222 + 1 or 2 +
(SmartShutter only). Second byte indicates Shutter A
1 – 144
(1) or B (2). The third byte contains a value of 1
DE + 01 or 02 +
through 144 indicating the number of microsteps.
01 – 90
10111100 +
00000001 or
00000010+
00000001 -
10010000
223 Instructs the controller to collect the next four
wheel/shutter commands. Once received, the four
DF
commands are executed in quick succession. This
11011111
command was introduced in the Lambda 10-2; it is
retained in the Lambda 10-3 for compatibility with
applications that already have this functionality
programmed.
NOTE: This batch command does not support Wheel
C – use the Batch Start and Batch End command
sequence instead if support for Wheel C is required.
LAMBDA 10-3 OPERATION MANUAL – REV. 3.03 (20110829)
Description Description Description Description
45
