Filter Wheel Commands; Table 5-3. Command Code Ranges - Sutter Instrument LB10-3 Operation Manual

The microprocessor in the controller is programmed to distinguish between these two types
of input commands based on the bit pattern of the command and will respond accordingly.
These two types of commands are discussed in more detail in the following sections.
The following table shows the command byte value ranges for filter commands and those for
shutter/special commands.
Filter Command Ranges Filter Command Ranges Filter Command Ranges Filter Command Ranges
Hexadecimal Hexadecimal Hexadecimal Hexadecimal
00 - 09
10 – 19
20 – 29
30 – 39
40 – 49
50 – 59
60 – 69
70 – 79
80 – 89
90 – 99
A0 – A9
B0 – B9
C0 – C9
D0 – D9
E0 – E9
F0 – F9

5.2 Filter Wheel Commands

5.2 5.2 5.2 Filter Wheel Commands Filter Wheel Commands Filter Wheel Commands
A byte command sent to the controller that contains a value from 0 through 121 decimal (00
through 79 hexadecimal) is interpreted as a Filter Wheel Command. Within a Filter Wheel

Table 5-3. Command Code Ranges.

Binary Binary Binary Binary Decimal Decimal Decimal Decimal
00000000
0 - 9
00001001
00010000
16 - 25
00011001
00100000
32 - 41
00101001
00110000
48 - 57
00111001
01000000
64 - 73
01001001
01010000
80 - 89
01011001
01100000
96 - 105
01101001
01110000
112 - 121
01111001
10000000
128 - 137
10001001
10010000
144 - 153
10011001
10100000
160 - 169
10101001
10110000
176 - 185
10111001
11000000
192 - 201
11001001
11010000
208 - 217
11011001
11100000
224 - 233
11101001
11110000
240 - 249
11111001
LAMBDA 10-3 OPERATION MANUAL – REV. 3.03 (20110829)
Shutter and Special Command Ranges Shutter and Special Command Ranges Shutter and Special Command Ranges Shutter and Special Command Ranges
Hexadecimal Hexadecimal Hexadecimal Hexadecimal Binary Binary Binary Binary
00001010
0A – 0F
00001111
00011010
1A – 1F
00011111
00101010
2A – 2F
00101111
00111010
3A – 3F
00111111
01001010
4A – 4F
01001111
01011010
5A – 5F
01011111
01101010
6A – 6F
01101111
01111010
7A – 7F
01111111
10001010
8A – 8F
10001111
10011010
9A – 9F
10011111
10101010
AA – AF
10101111
10111010
BA – BF
10111111
11001010
CA – CF
11001111
11011010
DA – DF
11011111
11101010
EA – EF
11101111
11111010
FA – FF
11111111
47
Decimal Decimal Decimal Decimal
10 - 15
26 - 31
41 - 47
58 - 63
74 - 79
90 - 95
106 - 111
122 - 127
138 - 143
154 - 159
170 - 175
186 - 191
202 - 207
218 - 223
234 - 239
250 - 255
