Safety Messages - Emerson Rosemount 8800D Series Reference Manual

Reference Manual
00809-0100-4004, Rev DC
Section 3
Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 21
Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 23
Hazardous locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 26
Hardware configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 26
Meter body installation tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 28
Electronics considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 35
Software configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 43
Transient protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 46
This section provides installation instructions for the Rosemount
Flowmeter. Dimensional drawings for each Rosemount 8800D variation and mounting
configuration are included in
The options available for the Rosemount 8800D Flowmeter are also described in this
section. The numbers in parentheses refer to the codes used to order each option.
3.1

Safety messages

Instructions and procedures in this section may require special precautions to ensure the
safety of the personnel performing the operations. Please refer to the following safety
messages before performing any operation in this section.
Explosions could result in death or serious injury.




Failure to follow these installation guidelines could result in death or serious injury.

Installation
Installation
Appendix A: Specifications and Reference
Do not remove the transmitter cover in explosive atmospheres when the circuit is
alive.
Before connecting a HART
sure the instruments in the loop are installed in accordance with intrinsically safe or
non-incendive field wiring practices.
Verify the operating atmosphere of the transmitter is consistent with the appropriate
hazardous locations certifications.
Both transmitter covers must be fully engaged to meet explosion-proof requirements.
Make sure only qualified personnel perform the installation.
®
-based communicator in an explosive atmosphere, make
Installation
May 2016
™
8800D Vortex
Data.
