Reference Manual
00809-0100-4004, Rev DC
Figure 5-11. Sensor Installation – Proper Alignment
Top View
of Flowmeter
A.Sensor
B. Sensor cavity in flowmeter
C. Sensor centerline must be aligned with flowmeter centerline.
3.
Troubleshooting
Proper Alignment
(before seating)
C
Sensor should remain as close to vertical as possible when applying force to seat.
See
Figure
5-12.
Troubleshooting
A
B
May 2016
87
