Chapter 3: BIOS Setup

Serial Port 2 Configuration

This section is used to configure serial port 2.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
Serial Port 2 Configuration
Serial Port [Enabled]
Device Settings IO=2F8h; IRQ=3;
Change Settings [Auto]
Onboard Serial Port 2 Mode [RS232]
Onboard Serial Port Max Baud Rate [115200 bps]
RS-485/422 receiver termination [Disabled]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Serial Port
Enables or disables the serial port.
Change Settings
Selects an optimal setting for the Super IO device.
Onboard Serial Port 2 Mode
Select this to change the serial port mode to RS232, RS422 or RS485.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Onboard Serial Port Max Baud Rate
Select this to change the max baud rate of the serial port.
RS-485/422 Receiver Termination
Enables or disables RS-485/422 receiver termination.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
