Chapter 3: BIOS Setup
BIOS Security Configuration
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Chipset
BIOS Security Configuration
RTC RAM Lock [Disabled]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
RTC RAM Lock
Enables or disables bytes 38h-3Fh in the upper and lower 128-byte bank of
RTC RAM lockdown.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
System Agent (SA) Configuration
Enable or disable bytes
38h-3Fh in the upper and lower
128-byte bank of RTC RAM
lockdown.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
VT-d
Enables or disables VT-d function on MCH.
Graphics Configuration
Configures the graphic chip settings.
NB PCIe Configuration
Configures the NB PCI Express settings.
Memory Configuration
Configures the memory settings.
41
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main Advanced Chipset Boot
System Agent Bridge Name Haswell
System Agent RC Version 1.5.0.0
VT-d Capability Supported
VT-d [Enabled]
Graphics Configuration
NB PCIe Configuration
Memory Configuration
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Security Save & Exit
Check to enable VT-d
function on MCH.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
