Chapter 3: BIOS Setup
Console Redirection Settings
Specifies how the host computer and the remote computer (which the
user is using) will exchange data. Both computers should have the same or
compatible settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
Out-of-Band Mgmt Port [COM0 (Disabled)]
Terminal Type [VT-UTF8]
[115200]
Bits per second
Flow Control [None]
Data Bits 8
Parity None
1
Stop Bit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Out-of-Band Mgmt Port
Enables or disables Microsoft Windows Emergency Management Services
(EMS) for allowing remote management of a Windows Server OS through
a serial port.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Terminal Type
ANSI
VT100
VT100+
VT-UTF8
Bits Per Second
Microsoft Windows Emergency
Selects the serial port transmission speed. The speed must match the other
Management Services (EMS)
allows for remote management
side. Long or noisy lines may require a lower speed.
of a Windows Server OS through
a serial port.
Flow Control
Flow control can prevent data loss from buffer overflow. When sending data
and the receiving buffers are full, a "stop" signal can be sent to stop the
data flow.
Data Bits
→←: Select Screen
↑↓: Select Item
Displays the current setting of Data Bits.
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
Parity
F3: Optimized Defaults
Displays the current setting of Parity.
F4: Save & Exit
ESC: Exit
Stop Bits
Stop bits indicate the end of a serial data packet. (A start bit indicates the
beginning). The standard setting is 1 stop bit. Communication with slow
devices may require more than 1 stop bit.
38
Extended ASCII character set.
ASCII character set.
Extends VT100 to support color, function keys, etc.
Uses UTF8 encoding to map Unicode characters onto 1
or more bytes.
