Preface

Package Contents

Before continuing, verify that the PEAK 887VL2 package that you received is complete. Your package should have all the items listed in the following table.
Item Part Number
1 10P0887VL00X0
2 60177B0268X00
3 60233ATA73X00
4 60233PRT15X00
5 603PS20001X00
6 60233SIO03X00
7 60233USB60X00
8 6029900037X00
9 602DCD0745X00

Optional Accessories

Item Part Number
1 60233DVI32X00
2 60233HDM01X00
3 60233US119X00
4 5050300481X00
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Name
ASSY PEAK 887VL2
PEAK 887VL2 Quick Reference Guide VER:B
SATA cable ACMELUX: 19922413
Cable CONNTEK: A02-C016-V01
PS2 Y CABLE CONNTEK:A02-A052-V01
Cable EDI: 13420901511-RS
USB cable CONNTEK: A02-B001-V01
DOW Corning 340 Silcone Heat Sink
Compound(3g)
PEAK 887VL2 DVD Driver VER:1.0
Name
DVI Cable ST:MD-6301035
HDMI Cable CONNTEK:A02-A039_V24
(N) USB 3.0 Cable ST:13-450-E007
LGA1156 CPU Cooler USE:FHSA9025S-1288
Description
PICMG 1.3 computing board
KRAMER
Standard L:300mm
Print 25 to 2.0mm 26-pin PIT:1.0mm L:260mm w/bracket
PS2 to JST 6P PH:2.0 L=250mm
COM port 9-pin to housing 10-pin
PIT: 2.0mm x2 L:150mm+-10mm
USB CONx2+bracket to JST 6-pin 2.5mm L:240+-15mm
JCL
Description
DVI 24+5P/F + bracket to DF13 2x15P PH:1.25 L:250mm
HDMI 19P/F + bracket to DF13 2x15P PH:1.25 L:250mm
USB A/Fx2 TO 2x10P L=380mm
88 x 88 x 36.7mm AL6063 7010FAN 4300RPM L:200mm
