Chapter 3: BIOS Setup

NB PCIe Configuration

Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PEG0 Not Present
PEG0 - Gen X [Auto]
PEG1 Not Present
PEG1 - Gen X [Auto]
PEG2 Not Present
PEG2 - Gen X [Auto]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PEG0 - Gen X
Configure PEG0 B0:D1:F0 Gen1-Gen3.
PEG1 - Gen X
Configure PEG1 B0:D1:F1 Gen1-Gen3.
PEG2 - Gen X
Configure PEG2 B0:D1:F2 Gen1-Gen3.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Memory Configuration
Configure PEG0 B0:D1:F0
Gen1-Gen3
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Memory Frequency Limiter
Configures the maximum frequency of the memory.
43
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Chipset
Memory Information
Memory RC Version 1.5.0.0
Memory Frequency 1600 Mhz
Total Memory 8192 MB (DDR3)
Memory Voltage 1.50v
DIMM#0 Not Present
Not Present
DIMM#1
DIMM#2 8192 MB (DDR3)
DIMM#3 Not Present
CAS Latency (tCL) 11
Minimum delay time
CAS to RAS (tRCDmin) 11
Row Precharge (tRPmin) 11
Active to Precharge (tRASmin) 28
XMP Profile 1 Not Supported
XMP Profile 2 Not Supported
Memory Frequency Limiter [Auto]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Maximum Memory Frequency
Selections in Mhz.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
