Chapter 2: Jumpers and Connectors
Jumpers
CMOS Clear Select
Connector type: 1x3 3-pin header
Connector location: JP7
1
3
Pin
Settings
1-2 On
Normal
2-3 On
Clear BIOS Setting
1-2 On: default
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
AT/ATX Select
Connector type: 1x3 3-pin header
Connector location: JP4
1
3
Pin
Settings
1-2 On
ATX Mode
2-3 On
AT Mode
2-3 On: default
8
PEAK 887VL2 User Manual
