Chapter 2: Jumpers and Connectors

DIP Switch

Connector type: 2x2 4-pin DIP switch
Connector location: SW1
2 1
Pin Description
SW1.1 OFF: Control by SW1.2
ON: PCIe x1
SW1.2
OFF: PCIe x4
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.

Debug Port

Connector type: 1x10 10-pin header, 1.0mm pitch
Connector location: J4
1 10
Pin Definition
1 GND
3 CLK_PCI_P80
5 LPC_AD3
7 LPC_AD1
9 VCC3
MH1 GND
21
Pin Definition
2 RST_SIO_N
4 LPC_FRAME#
6 LPC_AD2
8 LPC_AD0
10 VCC3
MH2 GND
