86
Note: You can select all instruments in Group Setup mode.
6. Press either the up arrow or down arrow key to select another
7. Repeat steps 5 and 6 until all you have identified all instruments in
Note: If you have more than eight ST60 or ST80 instruments, you
must create a second group with a separate identification code (for
example B1 , B2 etc.), operated by another remote keypad.
8. Use the arrow keys to select an instrument in the group to which
9. Press the up and down arrow keys together for 1 second. The
10. To allocate the ST7001+ to the selected group of instruments:
11. If you are creating more than one group, repeat steps 3 to 10 for
12. When you have set up all instrument groups, return to normal
ST7001+ Autopilot Control Unit - Owner's Handbook
Maxiview instruments: use the resp key to toggle between
•
group letter and sequence number, and the track key to set the
identifying character.
When you have identified the instrument, it should display its
group letter and sequence number, e.g. A2 .
instrument and repeat the procedure in step 5.
the group.
you want to allocate the ST7001+ as a keypad.
ST7001+ screen text will alternate between:
INST REM and KPD SETUP for standard instruments
•
MAXI REM and KPD SETUP for Maxiview instruments
•
Each instruments in the selected group will display PRESS KEY .
press the track or set crs key for standard instruments
•
press the resp or track key for Maxiview instruments
•
each group.
operation as follows:
• standard instruments:
press the track and set crs keys for 1 second to return to
•
Group Setup mode
then press the track and set crs keys again for 2 seconds
•
to return to normal operation
• Maxiview instruments:
press the resp and track keys for 1 second, to return to
•
Group Setup mode
press the resp and track keys again for 2 seconds to
•
return to normal operation.
