Chapter 7: Adjusting Autopilot Settings

Wind selection

Note: Only available if vessel type = SAIL BOAT and appropriate wind
data is available.
This screen determines whether the boat steers to apparent or true
wind in Wind Vane mode.
Options
WIND APP
WIND TRUE

WindTrim (wind response)

Note: Only available if vessel type = SAIL BOAT .
WindTrim (wind response) controls how quickly the autopilot
responds to changes in the wind direction. Higher wind trim settings
will result in a pilot that is more responsive to wind changes.
Screen text
WIND TRIM

Response level

This is the default autopilot response level. The response level
controls the relationship between course keeping accuracy and the
amount of helm/drive activity. You can make temporary changes to
response during normal operation (see page 7).
Autopilot steers to apparent wind angle (default):
• the autopilot will maintain the apparent wind angle
Autopilot steers to true wind angle:
• the autopilot will maintain the true wind angle
Options
Range = 1 to 9
Lower values (1 to 3) = autopilot responds to longer term
wind changes (less pilot activity)
Typical values = 4 to 6
Higher values (7 to 9) = autopilot responds to shorter term
wind changes (more pilot activity)
89
