Chapter 7: Adjusting Autopilot Settings

Response level

This screen determines the default response setting. This screen also
appears in User Calibration – see page 89 for full details (or refer to
the Appendix for Type 100/300 autopilots).

Turn rate limit

Note: Not available if vessel type = SAIL BOAT .
This limits your boat's rate of turn under autopilot control.
Screen text
TURN RATE

Off course warning angle

This screen determines the angle used by the OFF COURSE warning
(see page 10). The OFF COURSE warning operates if the pilot strays off
course by more than the specified angle for more than 20 seconds.
Screen text
OFF COURSE
AutoRelease (I/O drives only)
Note: Only available if vessel type = STERNDRV .
If the vessel type is set to STERN DRV (I/O or stern drive), you will see
the AutoRelease screen (AUTO RELEASE) set to ON as a default.
Range
1° to 30° per second in 1° steps
Range
15° to 40° in 1° steps
Locked heading
15˚ minimum
97
Boat heading
D3264-2
