Remotely Controlling St60 And St80 Instruments - Raymarine autopilot control unit Owner's Handbook Manual

34

3.5 Remotely controlling ST60 and ST80 instruments

You can use the ST7000+ to remotely control ST60 or ST80
instruments (both standard 110 mm and Maxiview instruments).
Note: Before attempting to remotely control ST60 or ST80
instruments, you first need to define the instrument grouping and
allocate the ST7001+ to the required group (see page 83).
To operate ST60 or ST80 instruments from the ST7001+ control unit:
1. Select either:
2. Carry out the required instrument control functions from your
Note: The currently-selected instrument is indicated as follows:
•
•
•
Controlling a standard instrument
Replicates the key-layout of the selected instrument.
For example: if you press resp, the selected instrument
responds as though its far left key has been pressed.
ST7001+ Autopilot Control Unit - Owner's Handbook
the INST REM data page (to control standard instruments), or
•
the MAXI REM data page (to control ST80 Maxiviews).
•
ST7001+ (using the keys shown in the following illustration).
on ST80 instruments, the characters are displayed as white
characters on a black background (instead of black on white)
on ST60 digital instruments, you will see a REMOTE message
on ST60 analogue instruments, you will see a flashing TRUE/MAG
and/or TRUE/APP message
Select instrument
All instrument types
Controlling a Maxiview instrument
Chapter
select
Page
select
D4325-2
