82
Available data pages
Speed Knots
Log
Trip
Average Speed, Knots
Wind Direction
Wind Speed
Depth Metres*
Depth Feet*
Depth Fathoms*
Heading
Water Temperature, Degrees C*
Water Temperature, Degrees F*
Course Over Ground
Speed Over Ground, Knots
Cross Track Error
Distance to Waypoint
Bearing to Waypoint
Rudder Gain
Response
Watch
Universal Time Coordinated
Remote Control for Standard
ST60/80 Instruments
Remote Control for
Maxiview Instruments
NOT USED
*NOTE: There are 3 depth pages (meters, feet and fathoms) and 2 water
temperature pages (°C and °F). The ST7001+ will display the water
temperature or depth data in the units defined by data page you select.
ST7001+ Autopilot Control Unit - Owner's Handbook
Displayed as
SPEED KTS
LOG XXXX.X
TRIP XXX.X
AV. SPD KTS
e.g. WIND PORT
WIND KTS
DEPTH M
DEPTH FT
DEPTH FA
HEADING
WATER °C
WATER °F
COG
SOG KTS
XTE
DTW
BTW
RUDD GAIN
RESPONSE
WATCH - used to control the Watch
timer (see page 32)
UTC
INST REM
MAXI REM
Page not displayed
(Any data page set to NOT USED is not
displayed when you scroll through the
data pages during normal operation)
