Chapter 7: Adjusting Autopilot Settings
Using data pages to set up ST60 and ST80 remote
control
Where the ST7001+ is used in conjunction with ST60 or ST80
instrumentation, you can use the ST7001+ to control the ST60 or
ST80 instruments by duplicating the functions of the Remote
Keypads used by these instruments. This means you can operate your
autopilot and ST60/ST80 instruments from the same location.
By using the INST REM and MAXI REM data pages, you can use
ST7001+ as a remote keypad to control any ST60 or ST80
instruments connected to it:
•
•
Each ST7001+ can control one group of up to eight standard
instruments and another group of up to eight Maxiview instruments.
Before you can use an ST7001+ to remotely control other
instruments, you must define the instrument grouping and then
allocate the ST7001+ to the required group.
Instrument grouping
Grouping allows you to create up to eight standard instrument and
eight Maxiview instrument groups:
•
•
•
•
•
the INST REM data page can control a standard (110 mm)
ST60/ST80 instrument group
the MAXI REM data page can control an ST80 Maxiview
instrument group
each group can have up to eight instruments
each group must have one or more remote keypads or an
ST7001+ grouped to it
each ST7001+ can be grouped with one ST80 Maxiview group
and one ST80/ST60 standard instrument group
each instrument in a group has a unique alphanumeric identity
(e.g. A1 , where A defines the group and 1 the instrument sequence
number within the group):
• standard ST60 or ST80 instruments are assigned group letters
from A to H
• maxiview instruments are assigned group letters from J to Q
• ungrouped instruments have a dash (-) in place of a group
letter
The instrument sequence number range is from 1 to 8.
