Accessing the Calibration mode

You can only access Calibration mode from Standby mode:
1. With the autopilot in Standby mode, press and hold the standby
2. Press the disp key or down arrow key to scroll down through the
Note: You can go backwards through the groups by pressing and
holding the disp key for one second or by using the up arrow key.
3. When you reach the Calibration group you want to access, press
4. When you have entered one of the Calibration groupings, press
Note: You can go backwards through the list by pressing and holding
the disp key for one second or by using the up arrow key.
5. When you reach an item you wish to adjust, use the -1 , +1 , -10 and
6. If you then want to adjust settings in another Calibration group,
7. When you have made all the changes you want to make, press and
ST7001+ Autopilot Control Unit - Owner's Handbook
key for 2 seconds. The display will change to show DISPLAY CAL .
4 calibration groupings:
Display Calibration (DISPLAY CAL)
•
User Calibration (USER CAL )
•
Seatrial Calibration (SEATRIAL CAL)
•
Dealer Calibration (DEALER CAL)
•
the auto key to enter that group:
To prevent accidental access, we have made entry to Dealer
Calibration more difficult than the other groups. After pressing
the auto key, the display will show CAL . When you see this, press
the -1 and +1 keys together to enter Dealer Calibration.
disp key or down arrow key to scroll down through the items
within that grouping:
+10 keys (as appropriate) to change the value.
press the standby key and then repeat steps 2 to 5 as necessary.
hold the standby key for two seconds to exit Calibration mode
and save changes.
