Off course warning angle
This screen determines the angle used by the OFF COURSE warning
(see page 10). The OFF COURSE warning operates if the pilot strays off
course by more than the specified angle for more than 20 seconds.
Screen text
OFF COURSE
AutoTrim
The AutoTrim setting determines the rate at which the autopilot
applies 'standing helm' to correct for trim changes caused by varying
wind loads on the sails or superstructure.You should set the default
AutoTrim after commissioning the autopilot (see page 73).
Setting
AUTO TRIM OFF
AUTO TRIM 1
AUTO TRIM 2
AUTO TRIM 3
AUTO TRIM 4

Power steer

If you have a joystick connected to your Type 100/300 autopilot
system, use power steer to select the required joystick mode of
operation (see table).
Options
POWER STR OFF
POWER STR 1
POWER STR 2
ST7001+ Autopilot Control Unit - Owner's Handbook
Range
15° to 40° in 1° steps
Effect
No trim correction
Slow trim correction
Medium trim correction
Rapid trim correction (default)
Very rapid trim correction
Power steer off
1 = Proportional power steer
Proportional power steer applies rudder in proportion to
joystick movement – the further the joystick is held over,
the greater the applied rudder.
2 = Bang-bang power steer
Bang-bang power steer applies continuous rudder in the
direction of the lever movement – to improve control, the
speed of rudder movement changes with the angle of the
lever. For maximum speed, push the lever hardover. If you
return the lever to the center position, the rudder will
remain in its current position.
