DPS Telecom NetGuardian 240T Hardware User Manual page 51

Table 13.1.1.A (Continued from previous page)
Display Points Alarm Point
59 GLD 1 fail
60 GLD 2 fail
61 GLD 3+ fail
Chan. Port
11
62
Timeout
63 Craft Timeout
64 Event Que Full
Description
GLD address 1 is failed.
GLD address 2 is failed.
One or more GLD units addressed 3 through
12 may be failed.
Chan. Port has not forwarded any traffic in
the time specified by the Channel Timeout
Timer. The channel feature forwards data
between two ports so the NG may be used to
analyze serial traffic using CHAN filter debug.
The Craft Timeout Timer has not been reset
in the specified time. This feature is
designed so other machines may keep the
TTY link active. If the TTY interface becomes
unavailable to the machine, then the Craft
Timeout alarm is set.
The Event Que is filled with more than 500
uncollected events.
System Alarms Descriptions
Solution
Connect just GLD unit 1 and
attempt to poll. Verify GLD is
connected to data port 8 and the
hardware is RS485, not RS232.
Verify the GLD unit addressing,
and test GLD units individually on
the GLD communication bus.
Reduce the number of connected
GLD units to determine which
unit may be causing the link to
fail.
Change the data port type to
OFF, or set the Channel Timer to
a different setting.
Change the Craft Timeout Timer
to 0 to disable the feature.
Enable DCP timestamp polling
on the master so events are
collected, or reboot the system
to clear the alarm.
47
