32
Operation
Help
Initialize NVRAM
Write NVRAM
Read NVRAM
View System Up Time
View Firmware Version
Data Port Description
Data Port Baud
Data Port Format
Data Port RTS Head
(msec)
Data Port RTS Tail
(msec)
Data Port Type
# of NetGuardian
Expanders
# of GLD or BSU
Timed Tick Period
System Name
System Location
System Contact
System Phone
Reboot
DCP Unit ID
DCP Port Number
DCP Port Type
DCP Protocol
DCP Autonomous Time
Network Time IPA
Username
Password
Access Rights
Network IPA
Subnet Mask
Command
get help
init nvram {g2}
set nvram
get nvram
get sysuptime
get prodid
{get,set} dataport {1...4} desc
{get,set} dataport {1...4} baud
{get,set} dataport {1...4} wfmt
{get,set} dataport {1...4} rtshead
{get,set} dataport {1...4} rtstail
{get,set} dataport {1...4} type
{get,set} ngddx
{get,set} gld
{get,set} timed tick
{get,set} name
{get,set} location
{get,set} contact
{get,set} phone
set reboot
{get,set} dcpaddr
{get,set} dcpport
{get,set} dcptype
{get,set} dcpprot
{get,set} dcpautotm
{get,set} ntpipa
{get,set} username {1...16}
set password {master, 1...16}
{get,set} access {1...16}
{get,set} net 1 ipa
{get,set} net 1 subnet
Params
None
None
None
None
None
None
string {0...15} chars
{1200,300,600,1200,2400,4800,
9600,19200,38400,57600,115200
}
{8n1,8n2,7n1,7e1,7o1,8
o2,8o1}
{0..255}
{0..255}
{off,tcp,ptcp,htcp,rtcp,udp,chan,
crft,cap,ecu,sps8}
{0...3}
{0...16}
{0...60} {min}
string {0..31} chars
string {0..31} chars
string {0..31} chars
string {0..20} chars
None
{0...255}
{1..32767}
{udp,tcp,serial}
{dcpx,dcpf,dcpe}
{0..120} {sec,min}
IP Address
string {0...18} chars
string {0..15} chars
{0000..01ff} where
Bit.0 – 1=admin
Bit.1 – 1=database
Bit.2 – 1=monitor
Bit.3 – 1=rly control
Bit.4 – 1=reachthru
Bit.5 – 1=modem
Bit.6 – 1=telnet
Bit.7 – 1=sd_monitor
Bit.8 – 1=ppp
IP Address
Subnet
