Backing Up Netguardian Configuration Data Via Ftp; Reloading Netguardian Configuration Data - DPS Telecom NetGuardian 240T Hardware User Manual

42

13.3.5 Backing Up NetGuardian Configuration Data via FTP

1. From the Start menu on your PC, select RUN.
2. Type "ftp" followed by the IP address of the NetGuardian you are backing up (e.g. ftp 126.10.120.199).
3. After the connection is made press Enter.
4. Enter the password of the NetGuardian (default password is dpstelecom), then press Enter.
5. Type "binary" and press Enter (necessary for NetGuardian file transfer).
6. Type "lcd" and press Enter (this allows you to change the directory of your local machine).
7. Type "get" followed by the name you wish to define for the NetGuardian backup file. Add the extension
".bin" to the file name (e.g. get ngdbkup.bin) and press Enter.
8. After reloading, type "bye" and press Enter to exit.
Note: The backup file name can have a maximum of eight characters before the file extension.

13.3.5.1 Reloading NetGuardian Configuration Data

1. From the Start menu on your PC, select RUN.
2. Type "ftp" followed by the IP address of the NetGuardian you are backing up (e.g. ftp 126.10.120.199).
3. After the connection is made press Enter.
4. Enter the password of the NetGuardian (default password is dpstelecom), then press ENTER.
5. Type "binary" and press Enter (necessary for NetGuardian file transfer).
6. Type "lcd" and press Enter (this allows you to change the directory of your local machine).
7. Type "put" followed by the name you defined for the NetGuardian backup file and press Enter (e.g. put
ngdbkup.bin).
8. Type "literal REBT" to reboot the NetGuardian.
9. After reloading, type "bye" and press Enter to exit.
