Application configuration

Using this parameter enables the choice of a
configuration (setting) of the frequency converter
that fits the application in which the frequency
converter is to be active.
NB!:
First, the motor nameplate date must be
set in parameters 102-106.

Setting of parameters

Select Speed control, open loop if a normal
speed adjustment without external feedback
Speed control, open loop:
Parame-
ter:
100 Configuration
200 Output frequency range/direction
201 Output frequency low limit
202 Output frequency high limit
203 Reference/feedback range
204 Minimum reference
205 Maximum reference
Select Speed control, closed loop if the application
has a feedback signal and the accuracy in
Speed control, closed loop (PID):
Parame-
ter:
100 Configuration
200 Output frequency range/direction
201 Output frequency low limit
202 Output frequency high limit
203 Reference/feedback range
414 Minimum feedback
415 Maximum feedback
204 Minimum reference
205 Maximum reference
417 Speed PID proportional gain
418 Speed PID integration time
419 Speed PID differentiation time
420 Speed PID diff. gain limit
421 Speed PID lowpass filter time
Please be aware that the encoder loss function
(parameter 346) will be active when parameter 100
is set to Speed control, closed loop.
76
There is a choice of the following configurations:
- Speed control, open loop
- Speed control, closed loop
- Process control, closed loop
- Torque control, open loop
- Torque control, speed feedback
The selection of special motor characteristics can be
combined with any application configuration.
signals is required (the internal slip compensation
is operating) from motor or unit.
Set the following parameters in order shown:
Setting:
Speed control, open loop
Only if [0] or [2] in par. 200
Only if [0] in par. 203
Speed control, open loop is not sufficient or a
full holding torque is required.
Set the following parameters in order shown:
Setting:
Speed control, closed loop
Output frequency low limit
Only if [0] or [2] in par. 200
Only if [0] in par. 203
MG.51.A9.02 - VLT is a registered Danfoss trademark
®
VLT 5000 Series
Data value:
[0]
Data value:
[1]
