made automatically, including the stator resistance
R . A manually entered R
S S
motor. The shaft performance can be improved by
fine-tuning R and X , see procedure below.
S S
Description of choice:
R can be set as follows:
S
1. Automatic motor adaptation, where the frequency
converter measures on the motor to determine the
value. All compensations are reset to 100%.
2. The values are stated by the motor supplier.
3. The values are obtained by means of
manual measurements:
- R can be calculated by measuring the
S
resistance R
PHASE-to-PHASE
terminals. If R
PHASE-to-PHASE
(typically motors >4-5.5 kW, 400 V), a special
ohm-meter should be used (Thomson bridge or
similar). R = 0.5 x R
S PHASE-to-PHASE
4. The factory settings of R
frequency converter itself on the basis of the
motor nameplate data, are used.
NB!:
If the setting in parameter 102-109 is changed,
the parameters 110-118 will return to factory
setting. If using special motor characteristics a
change in parameter 102-109 affects parameter 422.
109 Stator reactance
(STATOR REACT.)
Value:
depends on the choice of motor
Function:
After setting motor data in parameters 102-106, a
number of adjustments of various parameters are
made automatically, including the stator reactance
X . The shaft performance can be improved by
S
fine-tuning R and X , see procedure below.
S S
Description of choice:
X can be set as follows:
S
1. Automatic motor adaptation, where the frequency
converter measures on the motor to determine the
value. All compensations are reset to 100%.
2. The values are stated by the motor supplier.
3. These values are obtained by means of
manual measurements:
- X can be calculated by connecting a motor to
S
mains and measuring the phase-to-phase voltage
U as well as the idling current I.
L
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.51.A9.02 - VLT is a registered Danfoss trademark
must apply to a cold
between two phase
is lower than 1-2 ohm
, selected by the
S
®
VLT 5000 Series
Alternatively, these values can be recorded
during operation in idle running state at the
rated motor frequency f
(par. 115) = 0% and load compensation at
high speed (par. 114) = 100%.
4. The factory settings of X
frequency converter itself on the basis of the
motor nameplate data, are used.
NB!:
If the setting in parameter 102-109 is changed,
the parameters 110-118 will return to factory
setting. If using special motor characteristics a
change in parameter 102-109 affects parameter 422.
110 Motor magnetizing, 0 rpm
(MOT. MAGNETIZING)
Value:
0 - 300 %
Function:
This parameter can be used if a different thermal load
on the motor is desired when running at low speed.
This parameter is used in connection with
parameter 111.
Description of choice:
Enter a value stated as a percentage of the
rated magnetizing current.
Too low setting may lead to a reduced torque
on the motor shaft.
111 Min. frequency normal magnetizing
(MIN FR NORM MAGN)
Value:
0.1 - 10.0 Hz
Function:
This parameter is used in connection with parameter
110. See drawing in parameter 110.
, slip compensation
M,N
, selected by the
S
100 %
1.0 Hz
107
