Par. 204 Increase
Min. [Hz/V]
reference
1) 0 5
2) 10 4
3) 20 3
4) 30 2
5) 40 1
215 Preset reference 1 (PRESET REF. 1)
216 Preset reference 2 (PRESET REF. 2)
217 Preset reference 3 (PRESET REF. 3)
218 Preset reference 4 (PRESET REF. 4)
Value:
-100.00 % - +100.00 %
of the reference range/external reference
Function:
Four different preset references can be programmed
in parameters 215-218.
The preset reference is stated as a percentage of
the value Ref or as a percentage of the other
MAX
external references, depending on the choice made in
parameter 214. If a Ref
MIN
the preset reference as a percentage will be calculated
on the basis of the difference between Ref
Ref , following which the value is added to Ref
MIN
Description of choice:
Set the fixed reference(s) that is/are to be the options.
To use the fixed references, it is necessary to
have selected Preset ref. enable on terminal
16, 17, 29, 32 or 33.
Choices between fixed references can be
made by activating terminal 16, 17, 29, 32 or
33 - see the table below.
= factory setting. () = display text [] = value for use in communication via serial communication port
118
Frequency Par. 215
by 4.0 V Preset ref.
20 Hz 15 %
16 Hz 15 %
12 Hz 15 %
8 Hz 15 %
4 Hz 15 %
0.00%
≠ 0 has been programmed,
and
MAX
.
MIN
®
VLT 5000 Series
Par. 214 Reference
type = Sum [0]
Output frequency
00+20+7.5 = 27.5 Hz
10+16+6.0 = 32.0 Hz
20+12+4.5 = 36.5 Hz
30+8+3.0 = 41.0 Hz
40+4+1.5 = 45.5 Hz
Terminals 17/29/33 Terminals 16/29/32
preset ref. msb preset ref. lsb
0 0
0 1
1 0
1 1
See drawings in section Handling of multi-references.
219 Catch up/slow down value
(CATCH UP/SLW DWN)
Value:
0.00-100% of the current reference
Function:
This parameter enables the entry of a percentage
value (relative) which will either be added to or
deducted from the actual reference.
Description of choice:
If Catch up has been selected via one of the terminals
16, 29 or 32 (parameters 300, 305 and 306), the
percentage (relative) value selected in parameter
219 will be added to the total reference.
If Slow down has been selected via one of the terminals
17, 29 or 33 (parameters 301, 305 and 307), the
percentage (relative) value selected in parameter 219
will be deducted from the total reference.
221 Torque limit for motor mode
(TORQ LIMIT MOTOR)
Value:
0.0 % - xxx.x % of T
M,N
Function:
This function is relevant for all application
configurations; speed, process and torque control.
MG.51.A9.02 - VLT is a registered Danfoss trademark
Par. 214 Reference
type = Relative [1]
Output frequency
00+20+3 = 23.0 Hz
10+16+2.4 = 28.4 Hz
20+12+1.8 = 33.8 Hz
30+8+1.2 = 39.2 Hz
40+4+0.6 = 44.6 Hz
Preset ref. 1
Preset ref. 2
Preset ref. 3
Preset ref. 4
0.00%
160 % of T
M,N
