November 2003
REV A
Machine Torque Specifications
Platform rotator
1-8 center bolt
3
/
-16 bolts
8
Drive motor and hubs
Drive hub mounting bolts, dry
Drive hub mounting bolts, lubricated
Drive motor mounting bolts, dry
Drive motor mounting bolts, lubricated
Turntable bearing
Turntable bearing mounting bolts
Part No. 75861
480 ft-lbs
651 Nm
47 ft-lbs
63.7 Nm
220 ft-lbs
299 Nm
170 ft-lbs
231 Nm
25 ft-lbs
34 Nm
18 ft-lbs
25 Nm
210 ft-lbs
285 Nm
Genie Z-60/34
Section 2 • Specifications
SPECIFICATIONS
2 - 9
