Jib Boom / Platform Rotate Manifold Components (After Serial Number 4460) - Genie Z-60/34 Service Manual

Section 4 • Repair Procedures
JIB BOOM COMPONENTS
3-4
Jib Boom / Platform Rotate Manifold Components
(after serial number 4460)
Index
No. Description
1 Solenoid valve, 2 position 2 way ....... BE ......... Platform rotate
2 Orifice, 0.030 inch / 0.762 mm .......... BF ......... Platform rotate circuit
3 Orifice, 0.030 inch / 0.762 mm .......... BG ........ Platform rotate circuit
3
4 - 14
Schematic
Item Function
Jib boom up/down ............................. 20-25 ft-lbs / 27-34 Nm
1
BE
BG
Genie Z-60/34
November 2003
Torque
2
BF
Part No. 75861
REV A
