Secondary Boom Components; Secondary Boom - Genie Z-60/34 Service Manual

November 2003
REV A
a b
n
5-1

Secondary Boom

How to Disassemble the
Secondary Boom
Bodily injury hazard. The
procedures in this section require
specific repair skills, lifting
equipment and a suitable
workshop. Attempting this
procedure without these skills and
tools could result in death or
serious injury and significant
component damage. Dealer
service is required.
Follow the disassembly steps to the point required
to complete the repair. Then re-assemble the
secondary boom by following the disassembly
steps in reverse order.
Part No. 75861

Secondary Boom Components

c
m l k
Genie Z-60/34
d e
j i i
Secondary Boom
a
b
c
d
e
f
g
h
i
j
k
l
m
n
Section 4 • Repair Procedures
d
g
h
jib boom
extension tube
primary boom
upper leveling link
upper secondary boom
upper pivot
turntable pivot
primary boom lift cylinder
lower leveling link
lower secondary boom
secondary boom lift cylinder
mid-pivot
compression link
jib boom leveling link
f
4 - 25
