Manifold Component Specifications - Genie Z-60/34 Service Manual

November 2003
REV A
Manifold Component
Specifications
Plug torque
SAE No. 2
SAE No. 4
SAE No. 6
SAE No. 8
SAE No. 10
SAE No. 12
Valve coil resistance specifications
Description
Proportional solenoid valve, 12V DC
(schematic items AB, AC and AG)
(before serial number 4461)
Proportional solenoid valve, 12V DC
(schematic items HM, HO and HR)
(after serial number 4460)
Part No. 75861
50 in-lbs / 6 Nm
13 ft-lbs / 18 Nm
18 ft-lbs / 24 Nm
50 ft-lbs / 68 Nm
55 ft-lbs / 75 Nm
75 ft-lbs / 102 Nm
Specification
4 to 5Ω
3 to 4Ω
Genie Z-60/34
Section 2 • Specifications
SPECIFICATIONS
2 - 5
